Description
Camera adapters for attaching digital cameras to TM Series microscopes.
| Product | What it does |
|---|---|
| 0.5× Camera Adapter — C-Mount | C-mount relay adapter with a 0.5× reduction lens. It halves the optical magnification delivered to the camera, giving a wider field of view and a brighter image on the sensor—especially helpful with smaller sensors.
Parfocal adjustment may be required so the camera stays in focus when the eyepiece is in focus.
|
| Standard C-Mount Adapter | 1.0× projection adapter for connecting a C-mount camera without optical reduction. The camera sees a narrower field at higher on-sensor magnification, which increases pixels-per-millimeter for small-feature work.
If image appears dim, increase exposure or use brighter incident illumination; 1.0× passes less light per pixel than a 0.5× reducer.
|
Selection tip: choose the 0.5× adapter when you want a wider, brighter view (general documentation, training, overviews).
Choose the standard 1.0× adapter when you want more pixel density on small features for measurement. Confirm your TM head
has the appropriate photo/video port and that the adapter’s mounting diameter matches your configuration.
